Industrial silicon furnace's development

What is industrial silicon furnace?

Industrial silicon is also called crystalline silicon. The main use of industrial silicon is as an additive for non-ferrous alloys. Industrial silicon is also used as alloying agent for silicon steel with strict requirements, deoxidizer for smelting special steel and non-ferrous alloys. After a series of industrial treatments, industrial silicon can be pulled into monocrystalline silicon for use in the electronic industry.

Industrial silicon is now widely used in the preparation of alloys, the preparation of high-purity semiconductor materials, the production of solar cells, the production of temperature regulating materials and silicone. Today's society has entered the information age. In industrial developed countries, it has been widely used in scientific research, electrical, aviation, machinery, chemical industry, medicine, national defense and other fields.

Industrial silicon production is a high energy consumption industry, with an average consumption of more than 13000kwh per ton of industrial silicon, and more than 1.3 billion kwh per year of 1 million tons of industrial silicon in China. While the consumption per ton of silicon at the advanced level abroad is 11000kwh, the power consumption of industrial silicon in China is 10-20% higher than that at the advanced level abroad, and there is still great potential for energy conservation.

The high energy consumption of industrial silicon production in China is mainly due to unreasonable design and low control and management level.

The unreasonable design is reflected in many details, such as the widely used small furnace type of about 6300KVA in China (large heat dissipation and low output), the furnace type design is not strict in heat insulation measures, unreasonable circuit design, unreasonable size of polar circle and so on.

Energy saving ways of silicon metal furnace

From the perspective of professional furnace design and manufacturer, the energy saving ways in industrial silicon production currently considered by us mainly include:

1. Large scale of furnace type

2. Sealing direction of furnace type

3. Waste heat utilization direction

4. Measures to improve the electrical efficiency of the furnace, such as improving the short network structure design, improving the performance of the transformer, improving the electrical parameters, using low-frequency power supply, etc

5. Improve the thermal efficiency of the furnace

6. Change the reaction mechanism in the furnace

7. Change the performance direction of raw materials

8. Automatic direction control

9. Management system construction direction

Through years of exploration and discussion, the average electrical efficiency of industrial silicon arc furnace in China is more than 92%. Our company is also relatively mature in various technologies or measures to improve electrical efficiency, such as improving short network structure design, using high-quality conductive materials, adopting low-voltage compensation technology, improving electrical parameters, etc. However, the thermal efficiency of industrial silicon arc furnace in China is generally low, which is the main reason for the high energy consumption and low energy utilization efficiency of industrial silicon production in China. At present, our company has more experience and advantages in four aspects: the large-scale direction of furnace type, the sealing direction of furnace type, the utilization direction of waste heat and the heat insulation design technology.
